This product integrates SF6 humidity, SF6 purity, and SF6 decomposition product testing, consolidating functions that previously required three instruments into one instrument. One on-site measurement can complete the detection of three indicators, greatly saving gas in the equipment, reducing the workload of users, and improving work efficiency.

This product uses imported sensors; The humidity is measured using a pure imported high-precision humidity sensor, and the purity is measured using a thermal conductivity sensor with temperature compensation. The decomposition products are also measured using sensors imported from Europe. Color LCD display, real-time display of various parameters, touch control, foolproof operation, massive information storage, built-in rechargeable battery, dual-use for AC and DC.

Self calibration: The sensor probe can automatically calibrate the zero point, eliminate system errors caused by zero point and drift, and ensure the accuracy of each measurement.

Easy to operate, with a large touch LCD screen and simple WYSIWYG operation.

Optional pipeline cleaning device can be equipped to automatically clean internal pipelines after testing, improving testing speed and accuracy.

Fast gas saving: After starting up and entering the measurement state, the dew point measurement time is about 3 minutes each time.

Self locking connector: using original imported self-locking connectors, safe and reliable, without air leakage

Data storage: Designed with a large capacity, it can store up to 1000 sets of test data.

Clear display: The 7-inch large touch LCD screen directly displays dew point, micro water (ppm), SF6 purity, SO2, H2S, CO content, environmental temperature, environmental humidity, time, and date.

Built in USB interface, can be connected to a PC, and internal data of the instrument can be uploaded to the computer through supporting software for convenient data analysis.

Equipped with a large capacity rechargeable lithium battery, it can work continuously for more than 12 hours on a single charge.

純度：

測量范圍：0%~100%

測量精度：±0.5%

測量時間：小于2分鐘



露點：

測量范圍：-80℃~+20℃

測量精度：±1℃(-60℃~+20℃);±2℃(-80℃~-60℃)

響應時間(+20℃)：63%需5秒，90%需45秒(-60℃~+20℃)；63%需10秒，90%需240秒(+20℃~-60℃)



H2S：

測量范圍：1~200ppm

最小檢知量：≤0.1ppm

準確度：±0.5%

穩定性：0~200ppm

重復性：≤2%



SO2：

測量范圍：1~100ppm

最小檢知量：≤0.1ppm

準確度：±0.5%

穩定性：0~200ppm

重復性： ≤2%



CO：

測量范圍：1~500ppm

最小檢知量：≤0.1ppm

準確度：±0.5%

穩定性：0~500ppm

重復性：≤2%



顯示器件：3.5寸彩色液晶顯示器

工作溫度：-40℃~+60℃

環境溫度：- 40℃~+70℃

電量顯示：滿度比

環境濕度：-30~+60% RH

打印功能：熱敏微型打印機(選配)

尺寸：250×230×300 mm

重量：6.8公斤

電池性能：充電時間：10個小時；使用時間12小時以上

電源：AC 220V，內置充電電池

日期顯示：年、月、日

時間顯示：時、分、秒
